Tube Laser Cutting Machine

评级 5.00 / 5，已有 1 位客户进行了评价

Our advanced 5-axis laser cutting machine delivers high-performance, high-speed precision cutting for round, square, oval, U-shaped, and other special-shaped tubes. Capable of processing 6-meter-long pipes in a single operation, it’s ideal for fitness equipment, furniture, automotive, shelving, petroleum pipelines, and prop manufacturing. Boost productivity with unmatched accuracy and efficiency!

其他信息

Laser Power	1000W-6000W
Laser Brand	Raycus
Laser Wavelength	1070nm
Z Axis Move Distance	120mm
Pipe Thickness	0.5-12mm
Pipe Diameter	20-220mm
Pipe Length	≤6000mm
Positioning accuracy	±0.03mm/m
Repeat positioning accuracy	±0.02mm
Power Supply	380V/50HZ
Cooling Mode	Water Cooling
Operating temperature of machine	0℃-40℃
Operating humidity of machine	5%-90%
Machine Weight	4500KG
Machine Size	860024402130mm

5-Axis Laser Pipe Cutting Machine Precision & Efficiency for Special-Shaped Tubes

5-Axis Synchronization – Flexible cutting for complex special-shaped pipes | High-Efficiency Processing – High-speed cutting, 6-meter pipes completed in one pass, reducing secondary processing | Ultra-High Precision – Laser-cut with smooth, burr-free edges, accuracy up to ±0.1mm | Wide Material Compatibility – Supports carbon steel, stainless steel, aluminum alloy, and more

Equipment Advantages :

Multi-Directional Hole Cutting: Precisely cuts intersecting holes of different diameters and angles on main pipes, supporting both eccentric & concentric perpendicular intersections between branch and main pipes.
Complex Intersection Cutting : Processes cylindrical intersecting lines at branch pipe ends for perpendicular (eccentric/non-eccentric) and angled intersections with main pipes.
Beveled End Cutting : Accurately cuts angled end faces on round tubes for seamless welding and assembly.
Ring Main Pipe Intersections : Cuts branch pipe ends to perfectly fit curved/ring-shaped main pipes.
Square Pipe & 360° Cutting : Enables full rotational cutting on square pipes and complex profiles.
Hole Cutting on Round Pipes : Creates square holes, oval (waist-shaped) holes, and custom openings on round pipes.
Wide Material Compatibility : Cuts various carbon steel, stainless steel, aluminum, and other metal pipes with precision.
Heterogeneous Tube Processing : Performs intricate graphic cutting on square, oval, U-shaped, rectangular, and other special-shaped tubes.
Quick Clamping & Auto-Centering : Features fast-loading fixtures and automatic centering for efficient, high-precision production.

Machine Costruction & Featuresn

Gantry-Type Mechanical Structure: Compact Design, High Strength, and Precision

Heavy-Duty Construction: Built with a robust, gantry-type design, the system ensures maximum stability and strength, making it suitable for high-accuracy tasks in various industries.
Exceptional Durability: Crafted with advanced war industry techniques and annealing treatment, this structure promises long-lasting performance, with a lifespan of over 10 years under regular use.
Compact & Efficient: Despite its heavy-duty build, the gantry system occupies minimal space, providing high working efficiency and stable operation.
Impressive Performance: The machine delivers superior performance in demanding environments, maintaining accuracy and operational stability.
Weight: The entire system weighs approximately 3 tons, combining substantial strength with a manageable footprint.

Raycus Fiber Laser Generator CE Rackmount Ytterbium Fiber Laser Module

Low Energy Consumption: The Raycus Fiber Laser Generator boasts an impressive photoelectric conversion rate of 25-30%, making it significantly more energy-efficient than traditional CO2 laser cutting machines. With only about 20%-30% of the power consumption of traditional CO2 lasers, this unit helps save energy and protect the environment.
Long Lifespan: Designed for durability, the Raycus 6000W fiber laser has an exceptional lifetime of over 100,000 hours, ensuring minimal maintenance and reduced operational costs.
Low Maintenance: The fiber laser module requires almost no maintenance, reducing the need for frequent service and ensuring that your operations stay uninterrupted.
Global Service and Support: As a CE-certified product, the Raycus Laser Source is supported by Raycus Brand service centers worldwide, offering reliable, professional service wherever you are.

Cooling system : HL-2000 / HL-3000 / HL-4000 / HL-6000

Precision Temperature-Control Display Water Chiller ,our chiller’s compressor (imported famous brand), evaporator with high-quality titanium tubes (Stainless Steel Plate evaporator for non-standard products), circulating multi-stage pumps with stainless steel materials, refrigerant drying systems use filters, thermal expansion valve to get high-quality, high efficiency and low noise’s performance.

And turbo flow intellectual switch is for controlling the temperature of cooling water in laser lamp;the flow control is for ensuring long-term continuously operation of the laser generator.

Laser head with automatic Focuse Function

famous brand auto focus laser cutting head+follower system with condenser sensor, water cooling and anti-collision device function.

Can make much more faster penetrate than normal manual focus cutting head.

Gear & Rack System

KH Gear & Rack sytem, ensure hgh cutting speed with extremely precision position

Linear Guiderail

Higher speed noise volume is lower,ensure high accuracy and long service life.

Reduction Gear

Installed on Y axis,it can protect the ball screw transmission and keep the smooth operation of the machanism.

Drive System

Imported servo system ensures the possibility of realizing extreme precise positioning with the excellent dynamic response acceleration property and closed loop control method, and that makes moving positioning mechanism operate smoothly, reliably and free of maintenance;
Motors in X,Y,Z axis; loacation accuracy: ≤±0.04mm
X = 1.5KW, Y=1.8KW, Z=400W

Cypcut Operation Cut System Software,support AutoCAD,Coreldraw with FSCUT2000E ethercat control system

The professional cutting software which supports cutting path in dxf, plt and other graphic formats;capable of setting cutting parameters in different layers;combining joined lines to ensure automatic splice of curve nodes;smoothing fold lines to obtain smooth cuts;optimized immediately after the completion of graphic design,thus improve the productivity. By making use of the compensation function of this professional cutting software,various cutting accuracy grades may be obtained.

Gas Supply System:

The gas can flow away the cutting dust ,keep the clean of the machine and working enviroment;
Air, Oxygen and Nitrogen, Argon gas, Xenon gas and other inert gases can be used to cut. Oxygen cuts thicker than Nitrogen, but Nitrogen cuts smoother than Oxygen on the edge. Normally, customers will buy gas from local market, it's cheap and convenient, and customers can choose different gas to cut metals accroding to the metal thickness.

Accessory Optional

Air Compressor

International hotsale popular brand, high configuration, 11KW/15bar integrate type air compressor, can continuely stable supply high pressure air for cutting

Voltage Stabilizer

Stabilize the voltage at 380V, ensure machine can working under stable voltage

Industry Applications

Automotive & Aerospace
Exhaust pipes, structural components

Shelving & Storage
Industrial racks, display stands

Furniture & Architecture
Metal chairs, tables, railings

Oil & Gas Pipeline fittings, connectors

Product Parameters

Laser Power	1000W-6000W
Laser Brand	Raycus
Laser Wavelength	1070nm
Z Axis Move Distance	120mm
Pipe Thickness	0.5-12mm
Pipe Diameter	20-220mm
Pipe Length	≤6000mm
Positioning accuracy	±0.03mm/m
Repeat positioning accuracy	±0.02mm
Power Supply	380V/50HZ
Cooling Mode	Water Cooling
Operating temperature of machine	0℃-40℃
Operating humidity of machine	5%-90%
Machine Weight	4500KG
Machine Size	860024402130mm
